ML48-200

Open Circuit Voltage

48V~51V

Nominal capacity

200Ah

Based on 0.2C discharge current

Minimum capacity

200Ah

Initial impedance

≤150mΩ

AC 1KHz after standard Charge

Charge voltage

56V

Discharge cut-off voltage

40.5V

Standard charge current

40A

0.2C

Max. charge current

100A

Current limit

50A

Standard discharge current

40A

0.2C

Max. discharge current

200A

Operating temperature

0°C ~ +60°C

Charge

-20°C~ +60°C

Discharge

weight

88kg

Dimension

W*H*D=486*178*480mm

Excluding mounting ear

 W*H*D=440*178*480mm

Mounting structure and Height of the pack

19” standard rack size with 4U height
