ML48-100

Open Circuit Voltage

48V~51V

Nominal capacity

100Ah

Based on 0.2C discharge current

Minimum capacity

100Ah

Initial impedance

≤150mΩ

AC 1KHz after standard Charge

Charge voltage

54V

Discharge cut-off voltage

40.5V

Standard charge current

20A

0.2C

Max. charge current

100A

1C

Current limit

10A

Standard discharge current

20A

0.2C

Max. discharge current

100A

Operating temperature

0°C ~ +55°C

Charge

-20°C~ +55°C

Discharge

weight

46kg

Dimension

W*H*D=486*130*480mm

Excluding mounting ear

 W*H*D=440*130*480mm
